HVAC Units

Chemietron has vast expertise in the designing of the HVAC systems for various Cleanroom applications.  We guarantee that our designed and installed systems meet the required Clean Room classification as well as the current international GMP standards - including those of EU and USA.  The central devices used are of the highest quality with low running costs and have low maintenance requirements. Energy conservation is always an important part of our design.  The AHUs used are specially made for the intended application and are very robust in construction giving our clients reliable operation throughout the project life.

Selection Parameter : -

• Type  Floor Mount / Wall Mount / Horizontal / Vertical
• Design  Blow Through / Draw Through
• Frame Work :Thermal Break / Non Thermal Break
• Panel MOC : Double Skinned / Singled Skinned
• Base Frame : GI Skid with Corner / ‘C’ Channel
• Outer Sheet : Pre-Coated with PC / Powder Coated
• Inner Sheet :   Plain GI / Pre-Coated / SS
• Panel Thick :    25mm / 45mm
• Insulation :       Injected PUF @ 40±5 Kg/m3
• Static Pressure :    50mm to 200mm WG
• Types of Drive :     Belt Driven / Plug Fan
• Types of Fan :        Backward Curved / Forward Curved
• Filtration Stage     Pre-Filter / Fine Filter / Bag Filter / HEPA Filter
• Filter Condition     Differential Pressure Port
• Nos. of Damper    SA / RA / FA / PA
• Type of Damper    Aerofoil / GI Powder Coated
• Types of Zone       Inlet Lower with bird Screen

Return Air Plenum with RA / FA Damper

Pre-Filter Section / Bab Filter Section

HW / Steam / Heater Section

CHW / DX Coil Section

Mist Eliminator

Fan Section

Fine Filter Section
