Class 100 Trolley

Class 100 Trolley

70000.00 INR/Piece

Product Details:

  • Material Stainless steel
  • Voltage 220-240 Volt (v)
  • Weight 200-300 Kilograms (kg)
  • Application Industrial
  • Dimension(L*W*H) 1) 750 x 750 x 1950 2) 750 x 1065 x 1950 3) 750 x 1370 x 1950 Foot (ft)
  • Supply Ability : 5 Unit Per Month
  • Click to view more
X

Price And Quantity

  • 70000.00 INR/Piece
  • 1 Unit

Product Specifications

  • 1) 750 x 750 x 1950 2) 750 x 1065 x 1950 3) 750 x 1370 x 1950 Foot (ft)
  • Industrial
  • Stainless steel
  • 200-300 Kilograms (kg)
  • 220-240 Volt (v)

Trade Information

  • 5 Unit Per Month
  • 2-3 Week
  • Africa, Middle East, Western Europe, Eastern Europe, South America, North America, Central America, Australia, Asia
  • All India

Product Description

Backed with know-how and comprehension of years in this domain, we are proficient in manufacturing and exporting Class 100 Trolley. This trolley is made using superlative quality of raw materials that are procured from the reliable vendors of the market. We provide this trolley to variegated industries for the purpose of transferring sterile materials from one place to another in ISO class 5 particle free work area. This Class 100 Trolley is also provided with differential pressure gauges.

Features:

  • Two Stage Filtration
  • Horizontal & vertical air flow
  • SS Castor Wheel With Pu Coated



Mobile Trolley



Class 100 Trolley



Chemietron Designed For Transferring Sterile Products Under Iso Class 5 (Class 100) Particle Free Work Area. The Work Area Is Continuously Supplied With Positive Pressure Hepa Filtered Recirculated/Once Through Horizontal / Vertical Air Flow.

Technical Specifications:



  •     Air Cleanliness : Iso Class 5 / Class 100 / M 3.5 Area
  •     Air Velocities : 0.45 0.05 Mps (90 20 Fpm)
  •     Air Flow : Horizontal / Vertical
  •     Noise Level : Less Than 65 Db
  •     Vibration Level : Minimum
  •     Power Supply : 230V Ac,  1-,  50Hz
  •     Moc : Gi Powder Coated / Ss-304 / Ss-316 / Combination
  •     Two Stage Filtration
  •     Eu7 - Intermediate Filter (95% Down To 3 Micron)
  •     Eu14 - Hepa Filter - Supply / Exhaust (99.999% Down To 0.3 Micron)
  •     Statically & Dynamically Balanced Motor-Blower With Isolator To Reduce Noise Level
  •     Fluorescent Lights
  •     Uv Light
  •     Differential Pressure Gauges : 01 No. (Hepa Filter)
  •     Battery Back-Up With Inverter (For 30Mic. To Three Hour)
  •     Ss Castor Wheel With Pu Coated (With Locking Arrangement)
  •     On/Off Switches (Bl / Fl / Uv)
  •     Dop Port
  •     Dq, Iq, Oq, Pq Documentation

Options And Accessories:



A Wide Range Of Configurations To Suit Any Containment Application: -

    Once Through / Re-Circulating Operation
    Side Wall With Ss / Flexible Pvc Strip / Poly Carbonate / Acrylic Sheet)
    Velocity Display With High / Low Alarms
    Filter Chocking  Alarms
    Auxiliary Powder Socket :  5/15 Amp For External Equipment
    Flp Electrical Goods For Explosion
    Custom Design Available For Sterilized Drum Transfer



Specifications:



Model     Working Area
W X D X H     Over All Dimension
(Blower On Top Side)
Vertical Model     W X D X H
Cblf-22     610 X 610 X 610     750 X 750 X 1950
Cblf-32     610 X 915 X 610     750 X 1065 X 1950
Cblf-42     610 X 1220 X 610     750 X 1370 X 1950
