Dynamic Pass Box
40000.00 INR/Unit
Product Details:
- Feature 1)Noise Level: Less than 65 dB 2) Vibration Level: Minimum 3)Door: Swing Type Double Door (Double skinned) with View Panel With SS Hinges & ‘D’ Handle 4) In open any one door: UV will off and FL will on
- Application Industrial
- Material Stainless steel
- Type Pass Box
- Dimension(L*W*H) 1) 740 x 660 x 1275 2) 910 x 810 x 1425 3) 1065 x 980 x 1580 Millimeter (mm)
- Weight 80-150 Kilograms (kg)
- Voltage 220-240 Volt (v)
- Supply Ability : 5 Unit Per Month
- Click to view more
X
Price And Quantity
- 40000.00 INR/Unit
- 1 Unit
Product Specifications
- Pass Box
- Stainless steel
- 1)Noise Level: Less than 65 dB 2) Vibration Level: Minimum 3)Door: Swing Type Double Door (Double skinned) with View Panel With SS Hinges & ‘D’ Handle 4) In open any one door: UV will off and FL will on
- Industrial
- 80-150 Kilograms (kg)
- 220-240 Volt (v)
- 1) 740 x 660 x 1275 2) 910 x 810 x 1425 3) 1065 x 980 x 1580 Millimeter (mm)
Trade Information
- 5 Unit Per Month
- 2-3 Week
- Australia, Eastern Europe, Central America, Middle East, South America, Western Europe, Asia, North America, Africa
- All India
Product Description
We have marked a unique place in the market by manufacturing and exporting highly effective Dynamic Pass Box. This box is engineered under the supervision of trained professionals for transferring material from and into the clean room with safety to keep the environment safe from contamination. This Dynamic Pass Box can be fitted on the wall of clean room, with one of its opening in the other unclassified room. In this progression, the room door is not required to be opened.
Features:
- Bottom with heavy Roller base
- Internal Coving for easy cleaning
- Statically & Dynamically balanced Motor-blower
Dynamic Pass Box
Our world class range of Dynamic Pass Boxes are designed in conformation to the international standards and are used for transferring the material from and into the classified clean room without contaminating the air of clean room. In the process, room door is not required to open. These can be easily installed on the wall between the classified room and unclassified room.
Technical Specifications:
- Air cleanliness : ISO Class 5 / Class 100 / M 3.5 AREA
- Air Velocities : 0.45 ± 0.05 mps (90 ‚± 20 FPM)
- Air Flow : Horizontal / Vertical
- Noise Level : Less than 65 dB
- Vibration Level : Minimum
- POWER SUPPLY : 230V AC, 1-˜, 50HZ
- MOC : GI Powder Coated / SS-304 / SS-316 / Combination
- Door : Swing Type Double Door (Double skinned) with View Panel With SS Hinges & ‘D’ Handle
- Internal Coving for easy cleaning
- Two Stage filtration
- EU7 - Intermediate Filter (95% down to 3 micron)
- EU14 - HEPA Filter - Supply / Exhaust (99.999% down to 0.3 micron)
- Statically & Dynamically balanced Motor-blower with isolator to reduce noise level
- Fluorescent Lights (interlocked with Door)
- UV Light (interlocked with Door)
- Differential Pressure Gauges : 01 No. (HEPA Filter)
- Door Opening With Solid State Electronic Inter Locking Mechanism
- When both door closed; both are elec. Magnet locked; For open press touch screen to release the door
- At A Time Only One Door Opened
- Audio / Visual Indication for material is kept inside the pass box
- In close condition of both door : UV Light will be on,
- When open any one door : UV will off and FL will on
- DOP Port
- DQ, IQ, OQ, PQ Documentation
Options and Accessories
A wide range of configurations to suit any containment application:
- Bottom with heavy Roller base for drum / material transfer
- Flush level with ground level
- Flange for one side flush mount in clean room partition / wall
- FLP Electrical Goods for Explosion area
Specifications:
| Model | Working Area | Over All Dimension |
| CDPB-24/24 | 610 x 610 x 610 | 740 x 660 x 1275 |
| CDPB-30/30 | 760 x 760 x 760 | 910 x 810 x 1425 |
| CDPB-36/36 | 915 x 915 x 915 | 1065 x 980 x 1580 |
