SEPARATOR LESS HEPA FILTER

Immensely experienced in this industry, our organization is reckoned for manufacturing and exporting Separator Less Hepa Filter. This filter is made with anti-microbial treated papers and is available for use in various specifications. The uniform closed pleat from which this filter is composed of grants it a high crossing surface to hold minutest dust particles. Our Separator Less Hepa Filter is also tested according To En 1822 standards.

Features:

• Excellent finish
• Epoxy coated construction
• Highly efficient in filtering

Further Details:

Minipleated Hepa Filter

“Hygieno” Minipleat Filters Are Manufactured From Continuous Length Superior Quality Micro Glass Fiber Paper Media Available In Various Efficiency Grades. The Filter Media Is Moisture Resistant And Fire Retardant. Anti-Microbial Treated Papers Are Also Available For Special Applications.
The Uniform And Closed Pleat Filter Pack Grants A High Crossing Surface To Hold The Very Fine Dusts.

The Mini-Pleat Filters Construction Shall Have Extruded Anodized Aluminum Profiles.The Mini-Pleat Panel Filters Are Provided An Expanded Metal Mesh Face Guards On Downstream Side And Upstream Side.

The Filter Consists Of Micro-Glass Fiber Media In Efficiencies From 95% To 99.999995% @ Mpps (Filter Classes E10-U17 According To En 1822).

Description : -

·   Application:                Final Or Return Filtration For Clean Rooms

                                        Laminar Air Flow For Clean Benches

·   Type:                           High Efficiency Filter Panel

·   Case:                           Extruded And Anodizedaluminum.

·   Media:                        Micro-Fibre Glass

·   Separator:                  Hot-Melt Beads.

·   Sealant:                      Polyurethane

·   Gasket:                       Neoprene Rubber

·   Face guard                  Expanded Metal On Both Side, Powder Coated

·   En 1822 Efficiency:   H13 / H14

·   Mpps Efficiency:      H13:>99.95%, H14:> 99.995%.

·   Final Pressure Drop  400 Pa Recommended, 600 (Maximum)

·   Temperature:            70°C Maximum In Continuous Service.

·   Humidity                  100% Rh

     Test:                        100% Individually Tested According To En 1822

·      Low Initial Pressure Drop

·      Resilient

 Â·      Wide Range Of Standard Size

 Â·      Double Face guard

 Â·      Individually Tested According To En 1822

 Guaranteed Performance
